How to connect to a network

Connection example

Connecting a communication unit (DL Series) to the sensor amplifier allows data communication with various devices.

• Some models do not allow the connection of different types depending on the configuration.
• The maximum number of units connectable to one communication unit varies depending on the type of sensor amplifier.

Network example

• The PLC/PC needs to have a unit or a port that is compatible with the network.
• When RS-232C (DL-RS1A) is used for the connection, the unit is connected on a one-to-one basis.

Communication units and compatible networks

Various types of communication units are available to enable connection of any communication media.

DL Series communication unit lineup

EtherNet/IP® compatible DL-EP1	DeviceNet® compatible DL-DN1	CC-Link compatible DL-CL1	EtherCAT® compatible DL-EC1A	RS-232C compatible DL-RS1A
