MEASUREMENT & TEST METHOD IMPROVEMENTS

Using Non-contact Displacement Sensors to
Improve Measurement and Inspection Methods!

This document contains actual examples of inspection method improvements obtained by using non-contact displacement sensors as well as comments from KEYENCE customers who have installed displacement sensors.
We hope that you will read this document to see the know-how that KEYENCE has acquired over its history spanning more than 40 years as a direct sales manufacturer of displacement sensors.

Download catalog

Contact measurement

  • Measurement error varies depending on operators.
  • 100% inspections cannot be performed.
  • Thickness measurements vary for soft targets.
  • The cycle time cannot be improved.
  • Measurements of narrow locations cannot be performed.

Non-contact measurement

  • No measurement errors attributable to the operator.
  • 100% inspections are possible.
  • No need to worry about the contact pressure.
  • Workpieces are not damaged by the sensor.
  • The cycle time can easily be improved.
  • Measurements of narrow locations are also easy to perform.

RECOMMENDED ITEMS

Encouragement of Improvement in Measurement/Inspection Method [Contact VS. Non-Contact Measurement] (English)

Encouragement of Improvement in Measurement/Inspection Method [Contact VS. Non-Contact Measurement] (English)

  • [File type]PDF:762KB

Displacement Sensor/Measurement Instrument General Catalog (English)

Displacement Sensor/Measurement Instrument General Catalog (English)

  • [File type]PDF:6.35MB
