With 2D inspection, it is impossible to determine height information.
Inspection was not stable using only intensity information.
Depending on the background color, stable inspection may not be possible.
3D inspection of the terminals allows for judgment based on height.
Adding the height (Z) information to X/Y information enables inspection using volume or cross-sectional area.
Unlike conventional detection based on contrast differences in intensity information, profile changes and breaks can be detected easily.
For details, see the catalog.
